Home Product CNC Floor Type Boring Mills/CNC Table Boring Mills

CNC Floor Type Boring Mills/CNC Table Boring Mills

Phone

+8613503196313 Mr. Duan

allen@weipucnc.com

+8613503196313 Mr. Duan

Get a quote

Product description

TK69/TK65 boring mills are designed for the heaviest machining operations on large workpieces. The interaction of high-quality mechanical (casting) and control components guarantees high efficiency and accuracy in drilling and milling, turning and grinding.

Depending on the customer’s requirements and the field of application, the plate boring mills can be extended by the following modules:

+ Support sleeve spindles

+ Hydrostatic or linear guides

+ Controls from Heidenhain, Siemens or Fanuc

+ Tool changer

+ Cross slide

+ Rotary tables

+ Clamping plates

This increases the work contents per fixture. Through our network of technology partners, it is also possible to respond to the wishes of our customers with custom-made products.

CNC Floor Type Boring Mills
TECHNICAL DATA	TK6913	TK6916	TK6921	TK6926	TK6511	TK6513	TK6516
SPINDLE DIAM. [MM]	130	160	210	260	110	130	160
POWER OF SPINDLE MOTOR [KW]	22	31	37	37	22	22	31
RAM SIZE (W/L) [MM]	380*380	440*440	481*580	600*725	**	**	**
FEED RATE X-AXIS [ MM/MIN]	1-8000	1-8000	1-8000	1-8000	1-8000	1-8000	1-8000
FEED RATE Y-AXIS [MM/MIN]	1-8000	1-8000	1-8000	1-8000	1-8000	1-8000	1-8000
FEED RATE Z-AXIS [MM/MIN]	1-4000	1-4000	1-4000	1-4000	1-4000	1-4000	1-4000
CROSS TRAVEL OF COLUMN X-AXIS [MM]	3000-6000	4000-8000	6000-12000	8000-15000	1000-3000	1000-3000	1000-3000
VERTICAL TRAVEL OF SPINDLE HEAD Y-AXIS [MM]	2000-3000	3000-5000	3000-6000	3000-6000	1000-3000	1000-3000	1000-3000
AXIAL TRAVEL TO RUN Z-AXIS [MM]	700	800	1000	1800	1500-3000	1600-3000	1600-3000
TRAVEL TO SPINDLE W-AXIS [MM]	700	1000	1000-1200	1600	600	900	900
Support customization
